Specifications
|
|
Model
|
V24
|
|
Acceptable Media Width
|
720mm
|
|
Max.Cutting Width
|
620mm/24Inch
|
|
Operating system
|
Windows2000/XP/2003/win7/ 2003 x64/win7 x64/
MAC OSX10.2.8 & above version
|
|
Interface
|
RS232C,USB
|
|
Control Panel
|
10Silica gel buttons
|
|
Driver Digital
|
DC, Step Motor, Micro-step Driver
|
|
Display
|
4*8 High Resolution LCD
|
|
Drawing Instruction
|
|
|
Max. Cutting Speed
|
600mm/s
|
|
Max. Cutting Thickness
|
1mm
|
|
Pressure
|
50g~800g Adjustable
|
|
Mechanical Precision(mm)
|
0.025mm
|
|
Repeat Accuracy
|
0~1.0mm
|
|
Power Supply
|
AC90~240V/50Hz~60Hz
|
|
|
Bounded System,Random Original Point Setting
|
|
Work Mode
|
Roller
|
|
Operating Environment
|
Temperature:+5℃-35℃,Relative Humidity:30%-70%
|
|
Support Mode
|
Desktop / Stand (Optional)
|
|
Net weight
|
890*265*270mm / 12kg
|
|
Gross weight
|
1015*380*395mm / 16kg
|
|
Contour cut function
|
Optional
|
|
|
