App Typical application area
1. All manner of non-metal materials and marking on product’s surface:such as organic glass,ceramics,plastic,composite material,wood,rubber,leather,paper.
2. Electronics industry:capacitance,inductance,printed-circuit board,integrated circuitelectrical access card,various types of instruments and control panel.
3. Supplies and the clothing industry:the marking of cosmetic,foodstuff,button Liquor&Tobacco stationery and so on.
Parameters of Products
|
MODEL
|
UL10
|
UL30
|
UL50
|
UL100
|
|
Laser power
|
10w
|
30w
|
50w
|
100w
|
|
Laser wavelength
|
10.6μm
|
10.6μm
|
10.6μm
|
10.6μm
|
|
Power stability
|
±5%
|
±5%
|
±5%
|
±5%
|
|
The quality of laser beam M2
|
1.4±2
|
1.4±2
|
1.4±2
|
1.4±2
|
|
Cooling method
|
Air cooling
|
Close-lood/water-cooling
|
|
Laser marking the firstneedle
|
|
|
Scanning head
|
High-speed optical scanning galvanometer
|
|
Laser head dimensions
|
800×180×180nm
|
|
Marking area(mm)
|
50×50,70×70,105×105,140×140,175×175,210×210 or 255×255
|
|
Maximum marking speed
|
8m/s
|
|
Marking accuracy
|
0.05mm
|
|
Marking software
|
Specially designed laser marking software,with high power,simple menu mode of operation,can printing,a variety of chinese and English fonts,vector graphics,PLT and DXF file,BMP file,serial number(automatic numbered sequentially serial number),barcode and two-dimensional code,can mark on plane surface,cambered surface,cylinder and flying object.
|
|
Option
|
XY worktable,lifting table,rotary marking worktable
|
