Applicable Materials：
|
wood, paper, leather, cloth, organic glass, resin, acrylic, wollens, plastic, rubber, ceramic title, crystal, bowlder, bamboo etc nonmetal materials
|
|
Parameters of Products ：
|
|
Model
|
YL- 6040
|
|
Engraving Area
|
600×400mm
|
|
Engraving Speed
|
0-64000mm/min
|
|
Laser power
|
35w
|
|
Natural life of laser
|
3000hours
|
|
Laser wave length
|
10.6um
|
|
Resolution ratio
|
0.025mm
|
|
Minimum shaping character
|
Chinese character 2mm/ letter 1mm
|
|
Resetting positioning accuracy
|
±0.01mm
|
|
Power Supply
|
Ac220v±10%,50HZ
|
|
Gross Power
|
＜1250w
|
|
Operating Temperature
|
0℃-45℃
|
|
Operating humidity
|
5%-95%
|
|
Graphic Format Supported
|
BMP,GIF,JPEG,PCX,TGA,TIFF,PLT,CDR,DWG,DXF
|
|
Driver Type
|
Stepper Motor
|
|
Cooling
|
air and water cooling
|
|
Opearate System
|
Win98/Win2000/WinXP
|
|
Max Cutting thickness
|
≦10mm
|
|
Optional Configuration
|
①Auto moving platform②Rotary device, ③Cooling machine
|
|
Net Weight
|
100KG
|
|
Dimension
|
1200×900×900mm
|
|
